Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction machines. They make machines like manlifts, boom lifts and aerial lifts. These types of machinery are designed to facilitate access to difficult to reach areas, large equipment, buildings and roofs, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also known as OSHA refers to a power-driven endless belt. This belt moves just in one direction and includes steps or handholds or paltforms which are attached to the unit to be able to move personnel from every floor.
TB85
The TB85 by Terex offers a maximum working height of 91 feet. Moreover, the platform's maximum height reaches 85 feet. The maximum width of this model is 8 feet, 1 and 1/2 inches. The TB85 has dimensions measuring 9 feet, 1-inch high and 9 inches wide by 36 feet. This particular model provides a reach of seventy feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.
Terex TB100
The maximum working height of the Terex TB100 is 106 feet and the maximum height of the platform is 100 feet. When the TB100 is stowed it is 8 feet, 1 1/2 inches wide by 9 feet high by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's maximum working height overall reaches 116 feet. When stowed, this model is 9 feet, 4 inches high x 8 feet wide. The TB110 offers a maximum width of 8 feet and a horizontal reach of 67 feet. This model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
